Súng phun sơn tự động Iwata WA-101

Mô tả sản phẩm: Súng phun sơn tự động Iwata WA-101

	Model
Item	WA-101- 082P(V)	WA-101- 101P(V)	WA-101- 102P(V)	WA-101- 132P(V)
Type of feed	Pressure
Fluid nozzle orifice (mm)	0.8	1.0	1.0	1.3
Spray distance (mm)	200
Air pressure at gun inlet (MPa)	0.29
Air pressure in air cap (MPa)	-
Air consumption  (L/min)	270	90	270	260
Fluid output (mL/min)	150	100	200	250
Pattern width (mm)	190	140	220	230
Applied air cap model	E2P	E1	E2P	H2
Required air compressor (kW)	1.5	0.75	1.5
Mass (g)	440
Applications	Small  workpieces	small fluid  output	Small workpieces
