Mô tả sản phẩm: Yamaha MG82CX
MG82CX | MG124CX | MG166CX | ||
Total Harmonic Distortion |
Less than 0.1 % (THD+N) 20 Hz - 20 kHz @ +14 dBu (ST OUT) | |||
Frequency Response |
0, +1, -3 dB 20 Hz - 20 kHz @ +4 dBu (ST OUT) | |||
Hum & Noise *1 | -128 dBu Equivalent Input Noise/ -100 dBu Residual Output Noise 20 Hz - 20 kHz, Rs = 150 Ω, Input Gain = Maximum | -128 dBu Equivalent Input Noise/ -98 dBu Residual Output Noise 20 Hz - 20 kHz, Rs = 150 Ω, Input Gain = Maximum |
||
INPUT Connectors |
MIC: 4, LINE: 2 mono + 4 stereo, CH INSERT: 2, RETURN: 1 stereo, 2TR IN: 1 stereo |
MIC: 6, LINE: 4 mono + 4 stereo, CH INSERT: 4, AUX RTN: 1 stereo, 2TR IN: 1 |
MIC: 10, LINE: 8 mono + 4 stereo, CH INSERT: 8, AUX RTN: 1 stereo, 2TR IN: 1 |
|
OUTPUT Connectors |
ST: 1, EFFECT SEND: 1, CH INSERT: 2, REC: 1 stereo, MONITOR: 1 stereo, Phone: 1 |
ST: 2, AUX SEND: 1, EFFECT SEND: 1, CH INSERT: 4, REC: 1 stereo, MONITOR: 1 stereo, GROUP: 2 Phone: 1 |
ST: 2, AUX SEND: 2, EFFECT SEND: 1, CH INSERT: 8, REC: 1 stereo, MONITOR: 1 stereo, GROUP: 4 Phone: 1 |
|
Crosstalk *2 | -70 dB @ 1 kHz | |||
Phantom Power | + 48 V | |||
Input HPF | CH 1-2 and CH 3/4-5/6, 80Hz, 12dB/oct |
CH 1-4, CH 5/6-7/8, 80Hz, 12dB/oct |
CH 1-8, CH 9/10-11/12, 80Hz, 12dB/oct |
|
CH EQ (MONO) *3 ±15 dB (Max.) |
High | 10 k Hz: shelving | ||
Mid | 2.5 k Hz: peaking | |||
Low | 100 Hz: shelving | |||
CH EQ (STEREO) *3 ±15 dB (Max.) |
High | 10 k Hz: shelving | ||
Mid | — | |||
Low | 100 Hz: shelving | |||
Compressor (COMP) | control x 1 (Gain/Threshold/Ratio), CH 1-2 |
control x 1 (Gain/Threshold/Ratio), CH 1-4 |
control x 1 (Gain/Threshold/Ratio), CH 1-6 |
|
Internal Digital Effect | 16 PROGRAM, PARAMETER control Foot Switch (Digital Effect, on/off) | |||
LED Level Meter Pre MONITOR Level |
2 x 7 points LED meter (PEAK, +6, +3, 0, -5, -10, -20 dB) PEAK lights if the signal comes within 3 dB of the clipping level. |
2 x 12 points LED meter (PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB) PEAK lights if the signal comes within 3 dB of the clipping level. |
||
PEAK Indicator | Red LED turns on when post EQ (ST CH: or post Mic HA) signal reaches -3dB below clipping (17dBu). | |||
USB Audio USB IN/OUT |
— | — | — | |
Power Supply Adapter |
PA-10: AC 38VCT, 0.62A, Cable Length = 3.6m |
PA-20: AC 35VCT, 0.94A, Cable Length = 3.6m |
PA-30: AC 35VCT, 1.4A, Cable Length = 3.6m |
|
Power Consumption |
21 W | 30 W | 35 W | |
Dimensions (W x H x D) |
256.6 mm x 62.2 mm x 302.5 mm | 346.2 mm x 86.1 mm x 436.6 mm | 478 mm x 105 mm x 496 mm | |
Net Weight | 1.6 kg | 3.2 kg | 5.5 kg | |
Options | Microphone Stand Adaptor (BMS-10A), Foot Switch (FC-5) |
Foot Switch (FC-5) | Foot Switch (FC-5) | |
*1 Hum & Noise are measured with a 6 dB/octave filter @ 12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation. *2 STEREO L/R, CH 1-2, PAN panned Hard left or right @1kHz. *3 Turn over /roll-off frequency of shelving: 3 dB below maximum variable level. |
MG166-C-USB | MG166CX-USB | MG206C-USB | ||
Total Harmonic Distortion |
Less than 0.1 % (THD+N) 20 Hz - 20 kHz @ +14 dBu (ST OUT) | |||
Frequency Response |
0, +1, -3 dB 20 Hz - 20 kHz @ +4 dBu (ST OUT) | |||
Hum & Noise *1 | -128 dBu Equivalent Input Noise/ -98 dBu Residual Output Noise 20 Hz - 20 kHz, Rs = 150 Ω, Input Gain = Maximum |
|||
INPUT Connectors |
MIC: 10, LINE: 8 mono + 4 stereo, CH INSERT: 8, AUX RTN: 1 stereo, 2TR IN: 1 |
MIC: 10, LINE: 8 mono + 4 stereo, CH INSERT: 8, AUX RTN: 1 stereo, 2TR IN: 1 |
MIC: 16, LINE: 12 mono + 4 stereo, CH INSERT: 12, AUX RTN: 2 stereo, 2TR IN: 1 |
|
OUTPUT Connectors |
ST: 2, AUX SEND: 3, CH INSERT: 8, REC: 1 stereo, MONITOR: 1 stereo, GROUP: 4 Phone: 1 |
ST: 2, AUX SEND: 2, EFFECT SEND: 1, CH INSERT: 8, REC: 1 stereo, MONITOR: 1 stereo, GROUP: 4 Phone: 1 |
ST: 2, AUX SEND: 4, CH INSERT: 12, REC: 1 stereo, MONITOR: 1 stereo, GROUP: 4 Phone: 1 |
|
Crosstalk *2 | -70 dB @ 1 kHz | |||
Phantom Power | + 48 V | |||
Input HPF | CH 1-8, CH 9/10-11/12, 80Hz, 12dB/oct |
CH 1-8, CH 9/10-11/12, 80Hz, 12dB/oct |
CH 1-12, CH 13/14-19/20, 80Hz, 12dB/oct |
|
CH EQ (MONO) *3 ±15 dB (Max.) |
High | 10 k Hz: shelving | ||
Mid | 2.5 k Hz: peaking | |||
Low | 100 Hz: shelving | |||
CH EQ (STEREO) *3 ±15 dB (Max.) |
High | 10 k Hz: shelving | ||
Mid | 2.5 k Hz: peaking | |||
Low | 100 Hz: shelving | |||
Compressor (COMP) | control x 1 (Gain/Threshold/Ratio), CH 1-6 |
control x 1 (Gain/Threshold/Ratio), CH 1-6 |
control x 1 (Gain/Threshold/Ratio), CH 1-8 |
|
Internal Digital Effect | — | 16 PROGRAM, PARAMETER control Foot Switch (Digital Effect, on/off) |
— | |
LED Level Meter Pre MONITOR Level |
2 x 12 points LED meter (PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB) PEAK lights if the signal comes within 3 dB of the clipping level. |
|||
PEAK Indicator | Red LED turns on when post EQ (ST CH: or post Mic HA) signal reaches -3dB below clipping (17dBu). | |||
USB Audio USB IN/OUT |
Sampling Frequency = 44.1kHz or 48kHz (depend on the application of PC) | |||
Power Supply Adapter |
PA-30: AC 35VCT, 1.4A, Cable Length = 3.6m |
PA-30: AC 35VCT, 1.4A, Cable Length = 3.6m |
PA-30: AC 35VCT, 1.4A, Cable Length = 3.6m |
|
Power Consumption |
30 W | 35 W | 40 W | |
Dimensions (W x H x D) |
478 mm x 105 mm x 496 mm | 478 mm x 105 mm x 496 mm | 478 mm x 105 mm x 496 mm | |
Net Weight | 5.3 kg | 5.5 kg | 6.0 kg | |
Options | — | Foot Switch (FC-5) | — |
