| Specifications | ||
| Voltage DC | 175 - Accuracy* | ± (0.15%+2) |
| Max. Resolution | 0.1 mV | |
| Maximum | 1000 V | |
| Voltage AC | Accuracy* | ± (1.0%+3) |
| Max. Resolution | 0.1 mV | |
| Maximum | 1000 V | |
| Current DC | Accuracy* | ± (1.0%+3) |
| Max. Resolution | 0.01 mA | |
| Maximum | 10 A | |
| Current AC | Accuracy* | ± (1.5%+3) |
| Max. Resolution | 0.01 mA | |
| Maximum | 10 A | |
| Resistance | Accuracy* | ± (0.9%+1) |
| Max. Resolution | 0.1 Ω | |
| Maximum | 50 MΩ | |
| Capacitance | Accuracy* | ± (1.2%+2) |
| Max. Resolution | 1 nF | |
| Maximum | 10,000 µF | |
| Frequency | Accuracy* | ± (0.1%+1) |
| Max. Resolution | 0.01 Hz | |
| Maximum | 100 kHz | |
| Temperature | 179 - Accuracy* | ± (1.0%+10) |
| Max. Resolution | 0.1°C | |
| Range | -40°C/400°C | |
| Note | * | Accuracies are best accuracies for each function |
| Environmental Specifications | ||
| Operating Temperature | -10°C to +50°C | |
| Storage Temperature | -30°C to +60°C | |
| Humidity (Without Condensation) | 0% - 90% (0°C - 35°C) | |
| 0% - 70% (35°C -50°C) | ||
| Safety Specifications | ||
| Overvoltage category | EN 61010-1 to 1000 V CAT III. | |
| EN 61010-1 to 600 V CAT IV. | ||
| Agency Approvals | UL, CSA, TÜV listed and VDE Pending | |
| Mechanical & General Specifications | ||
| Size | 43 x 90 x 185 mm | |
| Weight | 420 g | |
| Warranty | Lifetime | |
| Battery Life | Alkaline: | ~200 hours typical, without backlight |
