Code: PTP35-A1C17H1BA8A |
73F2H-SM4AA1AEA4AA
50105031
**Prowirl 73F2H, DN200 8"
Vortex flow meter
For saturated steam and other mass flow
applications of gases and liquids
Flanged version, 2-wire technology
Implemented Gas and Energy calculator
One sensor for all line sizes
Life-time calibration ensures high
plant availability
Low cost of ownership due to
maintenance-free mechanical design
Mass balanced sensor ensures vibration
immunity and thus a reliable measurement
additional specification
Language English
S Measuring Tube Material: Stainless steel
CF3M/316L
M Process Connection: Cl.300 RF Sch.40,
flange ANSI
B16.5
4 DSC Sensor: High/low temp., 316L, -
200...+400oC
/-330...+750oF
A DSC Sensor Seal: Graphite, -200..+400oC
/-330...+750oF
A Calibration: 3-point
1 Additional Test, certificate: Basic version
A Approval: Non-hazardous area
E Version: Remote, cable 10m/30ft, IP67 NEMA4X
A Cable Entry: Gland M20 (EEx d> thread M20)
4 Display; Operating: 2-line display; push
button,
HART
A Adjustment; Software Feature: Factory setup;
basic version
A Output, Input: 4-20mA SIL HART + frequency |
PMC51-2AWA1/101
Cerabar M PMC51
additional specifications:
Low range value 0.000 mbar
Upper range value 400.000 mbar
2nd value display none
Damping [s] 00000002
Tag plate Stainless Steel 52006326
LT 1.8 0231A-BL1
LT 2.4 0231B-BL1
LT 3.4 0231C-BL1
(Code: PMC51-AA21JD1FGJAFFL+AAPAZ1) |
CLD132-PCS138AB1 Smartec S CLD132
No Product Details Available.
Feature model text Feature Length Feature text
Housing: P Compact
Process Connection: CS1 Clamp ISO2852 2"
Cable Entry: 3 Gland M20
Power Supply: 8 24VAC / DC
Output: AB 2x 20mA, conduct./conc. + temp.
Additional Option: 1 Basic version + temp.measurement fast
(CLD 132- P-CS1-3-8-AB-1) |
like SN: D303E714150
TR24-AB2AXGC000
60020989
RTD Thermometer TR24
without thermowell,
optional with compression fitting.
Replaceable insert, MgO.
Fast responsetime.
max. measuring range -200...600oC
(depending on configuration).
additional specification
Low range value 0,000 °C
Upper range value 175,000 °C
Commissioning label, paper 71072712
TT-501
A Approval: Non-hazardous area
B Head; Cable Entry: TA30A Alu, IP66/68; M20
2 Insert Diameter: 6 mm; 316L
A Compression Fitting; Ferrule: Not needed
X Immersion Length ML: 110 mm
G Head Transmitter; Range: TMT181 (PCP);
4-20mA, temp. range to be spec.
C RTD; wire; meas. range; class:
validity: 1xPt100 WW; 4; -200/600oC;
A; -200/600oC
0 Material Certificate: Not needed
0 Test/Calibration: Not needed
0 Additional Option: Not needed
TZ3 >>>Marking: Commissioning label, paper
(Model: TMT 181-A) |
like SN: D8005F010F1
FMI52-A1ATDJB1A1D
52027319
Liquicap M FMI52
Level measurement, capacitive.
Continuous.
Rope probe, fully insulated.
Application: liquids.
Total length of probe L = L1+L3.
:: Precalibrated 0-100% at factory for
conductive liquids.
:: Fast measurement reaction time.
:: Longtime stable tightness.
Self-adhesive paper label52006327
LT-702
A Approval: Non-hazardous area
1 Inactive Length L3: Not selected
A Active Probe Length L1; Insulation:
2.000 mm 316; FEP
TDJ Process Connection: Tri-Clamp ISO2852
DN40-51 (2"), 316L
B Electronics; Output: FEI50H; 4-20mA HART
1 Housing: F15 316L hygiene IP66/67 NEMA4X
A Cable Entry: Gland M20 (EEx d > thread M20)
1 Type of Probe: Compact
D Additional Option: EN10204-3.1 material
(316L wetted parts/pressurized),
inspection certificate
1 >>>Marking: Tagging (TAG), see additional
spec. |
like SN: D900AB010F0
FMI51-A1BTDJB1A1D (FMI51 - A1BTDJB1A1D)
52027317
Liquicap M FMI51
Level measurement, capacitive.
Continuous.
Rod probe, fully insulated.
Application: liquids.
Total length of probe L = L1+L3.
:: Precalibrated 0-100% at factory for
conductive liquids.
:: Fast measurement reaction time.
:: Longtime stable tightness.
Self-adhesive paper label52006327
LT-602
A Approval: Non-hazardous area
1 Inactive Length L3: Not selected
B Active Probe Length L1; Insulation:
300 mm, 16mm rod, 316L; PTFE
TDJ Process Connection: Tri-Clamp ISO2852
DN40-51 (2"), 316L
B Electronics; Output: FEI50H; 4-20mA HART
1 Housing: F15 316L hygiene IP66/67 NEMA4X
A Cable Entry: Gland M20 (EEx d > thread M20)
1 Type of Probe: compact
D Additional Option: EN10204-3.1 material
(316L wetted parts/pressurized),
inspection certificate
1 >>>Marking: Tagging (TAG), see additional
spec. |
like SN: D902B6010F0
FMI51-A1ATCJB1A1D (FMI51 - A1ATCJB1A1D)
52027317
Liquicap M FMI51
Level measurement, capacitive.
Continuous.
Rod probe, fully insulated.
Application: liquids.
Total length of probe L = L1+L3.
:: Precalibrated 0-100% at factory for
conductive liquids.
:: Fast measurement reaction time.
:: Longtime stable tightness.
Tag plate Stainless Steel 52006326
LT-102
A Approval: Non-hazardous area
1 Inactive Length L3: Not selected
A Active Probe Length L1; Insulation:
1.200 mm, 10mm rod, 316L; PTFE
TCJ Process Connection: Tri-Clamp ISO2852
DN25 (1"), 316L, EHEDG
B Electronics; Output: FEI50H; 4-20mA HART
1 Housing: F15 316L hygiene IP66/67 NEMA4X
A Cable Entry: Gland M20 (EEx d > thread M20)
1 Type of Probe: compact
D Additional Option: EN10204-3.1 material
(316L wetted parts/pressurized),
inspection certificate
1 >>>Marking: Tagging (TAG), see additional
spec |
like SN: D90B9001052
PMP135-A4G0CA1S (PMP 135-A4G0CA1S)
52013780
Cerabar T PMP135
Pressure transmitter, piezoresistive.
FDA compliant oil.
Measuring membrane: metal, flush mount.
Linearity +/-0,5%.
Process connections: hygienic.
Self-adhesive paper label52006327
PT-201
A4 Electrical Connection: Plug M12, IP65
NEMA4X
G Process Connection: Tri-Clamp ISO2852
DN25-38 (1...1-1/2"), 316L, DIN32676
DN25-40, EHEDG, 3A
0 Output: 4-20mA SIL
C Additional Option: EN10204-3.1
material (wetted parts), inspection
certificate
A1S Meas. Range; Sensor Overload Limit:
0...10bar/1MPa gauge; 40bar/4MPa
1 >>>Marking: Tagging (TAG), see additional
spec.
|
73W80-SK4AA1AEA4AA
**Prowirl 73W80, DN80 3"
(73W80-SK4AA1AEA4AW) |
73W50-SK4AA1AEA4AW (73W50_SK4AA1AEA4AW)
**Prowirl 73W50, DN50 2" |
71040104 Cable L=2m/80in PE >sep.housing
(FMB70-A B R 1H B 200 CNG) |
Code: FDU91-RG1AA |
Code: FMX167-A3BMF1A7
Waterpilot FMX167
Level measurement, hydrostatic.
Level probe.
Process membrane: CERAPHIRE, dry,rugged.
Output 4-20mA analog
Typ. ref. accuracy +/-0.2%
:: Integrated overvoltage protection.
Feature model text Feature Length Feature text
Approval: A Non-hazardous area
Connection: 3 G1-1/2, 304, cable-mounting-screw
Probe Tube: B 316L, d = 42mm/1,66in, flush mount
Measuring Range: MF 0...20mH2O
Sensor Seal: 1 FKM Viton
Probe Cable: A 2.00 ..... m, shortable, PE
Additional Option: 7 Basic version |
Amplifier Kit
P/N: 50106075 (5.0106.075) |
Board Kit Module communication
P/N: 50098303 (5.0098.303) |
Meas Amplifier Kit PW-72
P/N: 50103475 |
Thermocoupple type K
TAF16-13XNX030E0
High temperature applications in
cement production, steel treatment
and incinerators.
Exchangeable TC insert.
Ceramic or metallic protection sheath.
::Metal and ceramic sheath materials
with superior lifetime.
::Modular design.
Feature model text Feature Length Feature text
TC Type; Accuracy; Design: 13 1x K; class 2; wire diameter 3.26mm
Insertion Length He: X 1080 ..... mm
Pipe Diameter Dg; Material; max. Temp.: N 22.0 x 18.0mm; 310; 1100oC
Immersion Length Lg: X 200 ..... mm (200-2000)
Internal Protective Sheath; Diameter: 0 Not needed
Terminal Type: 3 Terminal block DIN B
Process Connection: 0 Not needed
Head; Cable Entry: E TA30A Alu, IP66/68; M20
Head Transmitter; Range: 0 Not needed |
FMB70-19C1/0
Model: FMB70-ABR1H1200CAA
Deltapilot S FMB70 |
Code: PTP35-A1C17H1BA8A |
Model: FTL50-1612/0
Liquiphant M FTL50
Feature model text Feature Length Feature text
Approval: A Non-hazardous area
Process Connection: GN2 Thread ANSI NPT1, 316L
Probe Length; Type: AA Compact; Ra<3.2um/126uin
Electronics; Output: 4 FEL54;SIL relay DPDT 19-253VAC/19-55VDC
Housing; Cable Entry: E5 F13 NEMA Type 4X/6P Encl. / F17 NEMA Type 4X Encl. Alu; NPT3/4 thread
Additional Option: A Basic version
(FTL50-A-GN2-AA-FEL54-E5-A) |
SOLIPHANT II FTM51-AGG2L4A32AA 500MM |
PMC51-AA21RC1CGJGMJA
Cerabar M PMC51
Low range value: -10kPa
Upper range value: 10kPa |
FMP57-AAACCALCB3GGE+LA
Levelflex FMP57, Probe: 5000mm |
Liquifloat T FTS20 AC/DC 5 m (16 ft) With CSM cable material
Order no: 52010124 |
73F2H-SM4AA1AEA4AA
50105031
**Prowirl 73F2H, DN200 8"
Vortex flow meter
For saturated steam and other mass flow
applications of gases and liquids
Flanged version, 2-wire technology
Implemented Gas and Energy calculator
One sensor for all line sizes
Life-time calibration ensures high
plant availability
Low cost of ownership due to
maintenance-free mechanical design
Mass balanced sensor ensures vibration
immunity and thus a reliable measurement
additional specification
Language English
S Measuring Tube Material: Stainless steel
CF3M/316L
M Process Connection: Cl.300 RF Sch.40,
flange ANSI
B16.5
4 DSC Sensor: High/low temp., 316L, -
200...+400oC
/-330...+750oF
A DSC Sensor Seal: Graphite, -200..+400oC
/-330...+750oF
A Calibration: 3-point
1 Additional Test, certificate: Basic version
A Approval: Non-hazardous area
E Version: Remote, cable 10m/30ft, IP67 NEMA4X
A Cable Entry: Gland M20 (EEx d> thread M20)
4 Display; Operating: 2-line display; push
button,
HART
A Adjustment; Software Feature: Factory setup;
basic version
A Output, Input: 4-20mA SIL HART + frequency
|
Code: 53W65-HC0B1AA0AAAA |
Deltabar S, PMD70-ABA7HBDABU1
Note: Please confirm the code |
50H50, DN50 2"
50H50-1PQ0/0 |
Deltabar S FMD78
FMD78-8ED2/0 |
Deltapilot S FMB70 TANK 5
FMB70-1TL8/0 |
Code: FTG20-AA34A1AB |
FTG20-13U8/0
Gammapilot FTG20
(Code: FTG20-AA34A1AB) |
Type: FTL20H-0TCJ2B
10-35VDC,PNP,3- Darht |
Code: FMU90-J21CB113AA1A |
Correct: FDU91-JN6AA
(Code: FDU91-JW6AA) |
Code: FMB70-ABR1PB2M3CAA |
Code: FTL20H-0UPJ2B |
MFTI55
Part no: FTI55-AAA1RV143A1A (FTI55AAA1RV143A1A) |
SENSOR,UNTRA-LEVEL: FDU93-RG4A
(SENSOR,UNTRA-LEVEL: FDU 83 RG4) |
SENSOR,TRANSDUCER: FMU90-R11CA131AA1A
(SENSOR,TRANSDUCER: FMU860) |
PMP51-FH01/142
PMP51-AA12IA1SGJGCJA1+PAZ1
Cerabar M PMP51
(Model : PMP51-AA121A1SGJGCJA1+PAZ1) |
PMD75-1C1F7/173
PMD75-ACA7LB12AEU
Deltabar S PMD75 |
Code: RIA 46 RIA46-A1C1A+A1 |
CARD CERRENT OUT
ORDER CODE: 50096757
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
CARD POWER SUPPLY 220VAC, 50HZ.
ORDER CODE: 71039431
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
CARD MEAS. AMPLIER
ORDER CODE: 50106094
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
Code: CPS11D-7BA21 |
Code: CYK10-A051, 5M |
Code: Cus31-A2A |
Spare part 71026754 electronic FMR 24*/25* HART Usage: FMR 250
(Spare part of type FMR250-AEE2GGJAA2K) |
Spare part T.NR: 52006197 F12 Terminal module
(Spare part of type FMR250-AEE2GGJAA2K) |
Code: 53W65-HC0B1AA0AAAA |
Deltabar S, PMD70-ABA7HBDABU1
Note: Please confirm the code |
50H50, DN50 2"
50H50-1PQ0/0 |
Deltabar S FMD78
FMD78-8ED2/0 |
Deltapilot S FMB70 TANK 5
FMB70-1TL8/0 |
Code: FTG20-AA34A1AB |
FTG20-13U8/0
Gammapilot FTG20
(Code: FTG20-AA34A1AB) |
Type: FTL20H-0TCJ2B
10-35VDC,PNP,3- Darht |
Code: FMU90-J21CB113AA1A |
Correct: FDU91-JN6AA
(Code: FDU91-JW6AA) |
Code: FMB70-ABR1PB2M3CAA |
Code: FTL20H-0UPJ2B |
MFTI55
Part no: FTI55-AAA1RV143A1A (FTI55AAA1RV143A1A) |
SENSOR,UNTRA-LEVEL: FDU93-RG4A
(SENSOR,UNTRA-LEVEL: FDU 83 RG4) |
SENSOR,TRANSDUCER: FMU90-R11CA131AA1A
(SENSOR,TRANSDUCER: FMU860) |
PMP51-FH01/142
PMP51-AA12IA1SGJGCJA1+PAZ1
Cerabar M PMP51
(Model : PMP51-AA121A1SGJGCJA1+PAZ1)
|
PMD75-1C1F7/173
PMD75-ACA7LB12AEU
Deltabar S PMD75 |
Code: RIA 46 RIA46-A1C1A+A1 |
CARD CERRENT OUT
ORDER CODE: 50096757
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
CARD POWER SUPPLY 220VAC, 50HZ.
ORDER CODE: 71039431
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
CARD MEAS. AMPLIER
ORDER CODE: 50106094
Used for PROMASS 80F
(CARD enclosed in the REMOTE) |
Code: CPS11D-7BA21 |
Code: CYK10-A051, 5M |
Code: PTC31-A2A11P1AE1A
Ceraphant T PTC31 |
Code: CPK1-200A |
40E25-AD2SAAA1A4AA
oder code: 40E25-1441/0 |
40E50-AD2SAAA1A4AA
Oder code: 40E50-15M1/0 |
E&H LEVEL GAUGE 260-0020
FTL260-0020 |
Correct: FMB70-ABA1P12M2CAA
(Model: PCB70-ABA1P12M2CAA) |
Model: PMP135-A1M01A1Q |
Code: PMP 131-A1101A1S |
Model: LT12-10024A1420 |
Model: AT1-126B05F1430 |
Model: LT12-10022A4320
Note: Can''''t offer |
Model: AT1-124B05F1430 |
P/N: 50108132
Kit display mod 50/51/80/65 >=V1.06.00 |
a complete system consisting of sensor and evaluating unit (2
parts)
here is complete specification:
Type: 80F50-AD2SAAHCAAAA
Promass 80F50, DN50 2"
Coriolis mass flowmeter
A - Measuring Tube Material: Stainl. steel D2S - Process Connection: PN40, 316L/1.4404, EN1092-1-B1 (DIN2501) flange A - Additional Test, certificate: Basic version A - Calibration: 0.15%, 0.0005g/cc H - Approval: ATEX II 3G EEx n IIC C - Housing: Remote, wall IP67 NEMA4X + 10m/30ft cable A - Cable Entry: Gland M20 (EEx d > thread M20) A - Power Supply; Display: 85-260VAC; WEA, 2-line + push buttons, WEA= language DE+EN+FR+IT+ES+PT+NL A - Adjustment; Software Feature: Default liquid; Basic version A - Output; Input: 4-20mA SIL HART + frequency |
a complete system but compact in 1 housing here are the details:
Type: FTM50-AGG2A4A32AA
Soliphant M FTM50
Point level switch, vibronic.Application: solids.Material: 316L.Grain size
<=10mm.Application: generatin dust, fluidised,powdery to fine-grained bulk
solids.:: Independent of solids characteristic.:: No maintenance needed.
A - Approval: Non-hazardous area
GG - Process Connection: Thread EN10226 R1-1/2
2 - Material; Surface Refinement: 316L; Ra<=3.2um/126uin, w/o A - Fork; Bulk Density: 155mm/6inch; min 10g/l
4 - Electronics; Output: FEM54; relay DPDT, 19-253VAC/55VDC A - Type of Probe: Compact
3 - Housing: F17 Alu IP66/67 NEMA4X
2 - Cable Entry: Gland M20 (Ex d > thread M20) A - Additional Option 1: Not selected A - Additional Option 2: Not selected |
GAMA Pilot DG27 (Detector DG 27)
Note: NO LONGER AVAILABLE; NO SUCCESSOR |
Type: 53H04-UF0B1AC1ABAA
53H04-15W6/0
Promag 53H04, DN04 5/32" |
Correct: RSG40-E211B1A1A1A1
Memograph M RSG40
(RSG40-E211B1B1A1A1) |
Type: TST310-B1A1A3G8B1A
Widerstandsthermometer TST310 |
L=200mm (shortest possible)
Type: TMT121-A31BA
iTEMP TMT121, DIN rail PCP
|
TR25-AB21X42000
Immersion Length Ml: 50mm |
Electronics FEI50H, 4-20mA, HART
Order code: 52028260 |
Code: FTL20H-0UPJ2B |
Code: PTP31-A1C13P1AF4A |
CPS11D-7BA21
PH SENSOR,0-14PH |
FMB70-5K11/0
Deltapilot S FMB70
(FMB70-ABT1M12UECAA) |
FMB70-1462/0
Deltapilot S FMB70
(FMB70-AAA1M1200CAA) |
FTL20H-0UPJ2D
Liquiphant T FTL20H
(FTL20H-0UPJ2D DC-PNP) |
Code: TR13-AER1TASF42000 |
Code: TR13-AER1TASH42000 |
Code: PMC131 - A11F1A1S |
Code: PMP 135-A4N01A2S |
Type: TST310-B1B1A4A8C1A
L: 9000mm
(RTD Thermometer PT100
Type: TST310-B1B1A4A9C1A) |
Cerabar T PMP131
Type: PMP131-A2211A1G |
Cerabar T PMP131
Type: PMP131-A2211A1R |
Code: FTL51-1K4P5/0 |
Code: FMP56-48D1/0 |
Level Switch
Soliphant M FTM50
Type: FTM50-AGG2A4A12AA |
Replaced by: TFTL20-062D
(F61D5301092) |
Code: TFTL20-062D |
Model: CLM223-ID1005 |
Article: 53P65-AH0B1AA0ABAA |
Khafagiventuri QV316, Flume higher
Primary element: Flume with
higher side walls.
Material: Polypropylene.
Channel height: 1800mm.
Channel width: 1600mm.
Max flow 3000l/s / 10800m3/h. |
Order code: TMT162R-M2B31U35X0
Serial No: D5004914323
RTD Thermometer TMT162R to screw-in.
Field housing NEMA 4x, IP67.
HART protocol, Foundation Fieldbus protocol, Profibus PA protocol.
Namur NE43.
Replaceable insert, MgO.
max. measuring range: -200...600°C
additional specification
Low range value 0,000 °C
Upper range value 200,000 °C
Failure mode (1 = low <3.6mA, 2 = h 00000002
M-Housing Material; Approval: Alu, ATEX II
1/2GD
EEx d IIC T6
2-Cable connection; Display: M20x1.5; + display
B-Configuration; Communication: Pt100; HART
3-Neck Length N; Type: 96 mm; nipple + coupl.
type
LC
1-Thermowell Type: Bar stock, to order
separately
U-Thermowell Connection: Thread M24x1.5-F
3-Inset Diameter; Material: 6mm; 316L
5-RTD; wire; meas. range; class: validity:
2xPt100
WW; 3; -200/600oC; A; -200/600°C
X-Insertion Length Ml: 178 mm
0-Factory Test: Not needed |
Sensor Liquidphant T FTL20-062D
Ser.no: F61D5301092 |
LevelFlex M FMP40-APP2CRJB11AA
Ser.No: F703890104E
Note: pls check the Ser.No: F703890104E, we needs know the Probe length, the price is for probe length 600mm. |
LevelFlex M FMP40-APP2CRJB11AA
Ser.No: F703890104E
Note: pls check the Ser.No: F703890104E, we needs know the Probe length, the price is standard for probe length 1120mm |
CPS441D-75B21
Tophit CPS441D |
CYK10-A101
Meas. cable CYK10 Memosens
(CYK10-A101**) |
CM442-7FW4/0
CM442-AAM1A2F260A+AAQ3Z1
Liquiline CM442
Note: In Case of order, please indicate needed Tag Marking
(CM442-AAM1A2F260A+AAQ3Z1) |
Code: FTL20-0135
(FTL20-0135 AS-i) |
TR45-BF5X1S3HG0000
length: L= 150mm |
Pressure transmitter, capacitive.
Type: PMC131-A11F1A1S
Cerabar T PMC131 |
Replaced by: PMP51-12JU8/125
Cerabar M PMP51
Acc. SN FB060E01129
(Pressure sensor cerabar M
Type: PMP41-RE23ZBP) |
Pressure sensor cerabar M
Type: PMP51-1XEP1/0
(Pressure sensor cerabar M
Type: PMP41-RE23ZBP) |
Pressure transmitter, capacitive.
Type: PMC131-A11F1A1S
Cerabar T PMC131 |
Replaced by: PMP51-12JU8/125
Cerabar M PMP51
Acc. SN FB060E01129
(Pressure sensor cerabar M
Type: PMP41-RE23ZBP) |
Model: 942511-0002
Note: item was discontinued without successor |
Hydrostatic Level Transmitter
FMB53-FFA7/101
FMB53-AA21JC1MGJ15B3A
Deltapilot M FMB53
Level, hydrostatic.
Rope, separate mounting.
Application: liquids.
Membrane: CONTITE,
welded, climate proof.
:: Easiest on-site operation.
:: Modular.
additional specification
Low range value 0,000 mmH2O
Upper range value 16.000,000
mmH2O
2nd value display none
Damping [s] 00000002
AA Approval: Non-hazardous area
2 Output: 4-20mA HART
1 Display, Operation: LCD, push
button on
display/electronics
J Housing: F31 Alu, Glass window
C Electrical Connection: Thread G1/2,
IP66/68
NEMA4X/6P
1M Sensor Range: 4bar/400kPa/60psi gauge,
40mH2O/133ftH2O/1600inH2O
G Reference Accuracy: Standard
J Calibration; Unit: Customised
pressure; see
additional spec.
15 Probe Connection: 20,00 m cable,
shortable, PE
B Membrane Material: AlloyC
3 Fill Fluid: Synthetic oil, FDA
A Seal: FKM Viton
VGS: PEB
(FHB20
Model: DB53-AM70BD11GF2A
Ser Nr: AB006B01032)
|
Code: FHB20
Note: Please confirm the code |
Replaced by: FMB53 AA21JC1MGJ15B3A
1 meter connection cable
(FEB22
Model: DB53-AM70BD11GF2A
Ser Nr: AB006B01032) |
Endress Hauser Ceraphant T:
Order code: PTP35-A4B13HTDB4A
(PTP35A4B13HTDB4A) |
Code: PMC131-A11F1A1S |
PRESSURE TRANSDUCER
PMC131A11F1A1R |
Sensor
CPS12D-7NA21 |
Transmiter
PMC71-HBA1C2GABAA |
Flowmeter
80A04-2E02/0
Promass 80A04, DN4 1/ 8" |
Presure transmiter
Code: PTP35-A4B13HTDB4A |
CLM253-CD0005 (CLM253_CD0005)
Dải: 0 – 2000mS/cm |
Flow Controller
Model: 53W80-UL0B1AC1BAAB |
Flowmetter
50H65-1118/0
Promag 50H65, DN65 2 1/2"
(50H65-UF0A1AA0AAA
PROMAG H,
Order code : 50H65-UF0A1AA0AAA.
Serial : 9101FB18000, DN65 PN16 , 0.5% CAL . Material : PFA EPDM ,
Electrode : 1.4435/316L, EPD/MSU) |
Code: 50H65-UF0A1AA0AAA |
Flowmetter
50H40-1123/0
Promag 50H40, DN40 1 1/2"
(50H40-UF0A1AA0AAA
PROMAG H,
Order code : 50H40-UF0A1AA0AAA.
Serial : 92019F18000, DN40 PN16 , 0.5% CAL . Material : PFA EPDM ,
Electrode : 1.4435/316L, EPD/MSU) |
Code: 50H40-UF0A1AA0AAA |
Type: TR44-EA5XAS2HGP000 |
Type: FTL20-0020 |
Type: TR44-EA5XAS2HAP000 |
Type: PMP135-A3N01A2S (PMP 135-A3N01A2S) |
Model: RMS621-21AAA1111 |
Flowmeter
Code: 72W40-SD0BA1AAA4AA
(Code: 72W40-SDOBA1AAA4AA) |
Temperature Sensor TR24
Code: TR24-GB1DBC3000 |
Code: TR44-BB5AAS2HAP000 |
Code: PMP135-A4N01A2S
Ser.No: E5010B01052
(PMP135-A4NO1A2S) |
Replaced by: 11363Z-R1AA5C111EA
Connect:G1-1/2,
100*150*260mm
(Conductive Limit Detection, three-rod probes 11363Z-R1AA5D111EA,Connect:G1-1/2,chieu dai cac ty 100*150*260mm) |
PMC71-11TA0/156
52017196
PMC71-UBA1SBTRBAZ
additional specification
Low range value 0,000 bar
Upper range value 25,000 bar
Display at 4mA
Display at 20mA
Display unit
KRONES mod., sensor abs, gauge calibr.
71028491
(Code: PMC71-UBA9YBTRBAA) |
Pressure transmiter Cerabar S,
Order code: PMC71-ABA1K1TKBAA
PMC71-35V7/0
52017196 |
TR44-FB5YAS2HA2000
60017919
RTD Thermometer TR44
Range: -50...200oC.
additional specification
Low range value 0,000 °C
Upper range value 100,000 °C |
Sensor
Code: PMP135-A1G01A1S |
Capacitive level
Code: FTI77-A1CCRRV133B1A
L1:500mm |
TR45-FA5E1R2HGH00
Range : 0 - 150oC
Output : 4 - 20 Ma |
TR45-ND5X1R2HGH000
Range : 0 - 150oC
Output : 4 - 20 mA |
CERABAR M PMP46-JE17H1H1DGD
Range : -1 … +1 Bar
Output : 4 - 20 mA |
LIQUIDCAP M FTI51-GAB1TDJ25A1A
Chiều dài : 500 mm |
MINICAP
Code: FTC260-BA2D2 |
Float Gauge LT12
Order Number: LT12-10024A1420 |
Level Ultrasonic
Code: FMU40-ANB2A2 |
Code: 53H80-A00B1AA0ABAA |
Code: 72W1F-SE0AAPAAA4AA |
Code: 53P1Z-EH0B1AA0ABAA |
Code: FMI51-A1AGEJB3A2A |
Code: FTL20H-0GDJ2F |
Code: FTM50-4GG2A2A32AA |
Code: PMC131-A11F1A1R |
Code: FMB70-UCA1F1200CAA |
Code: PMC131-A11F1A1K |
Code: FMB70-UCA1M1200CAA |
Code: PMC71-UBA1SBRMBAZ
Zulassung: U CSA C/US IS Cl.I,II,III Div.1 Gr.A-G,
Cl.I Div.2 Gr.A-D, Ex ia,
C: Zone 0,1,2/ US: Zone 0,1,2,20,21,22
Ausgang; Bedienung: B 4-20mA HART; Innenliegend + LCD
Gehäuse; Deckeldichtung; Kabeleinf.: A T14 Alu IP66/67 NEMA6P; EPDM; M20
Verschraubung, T14 = Deckel seitlich
(Ex d > M20 Gewinde)
Sensorbereich; Sensor Überlastbereich: 1S 40bar/4MPa/600psi relativ;
60bar/6MPa/900psi
Kalibration; Einheit: B Kundenspezifisch; siehe Zusatzspez.
Prozessanschluss: GH Gewinde ISO228 G1/2 Bohr. 11.4mm, 316L
Dichtung: B EPDM
Zusatzausstattung 1: A nicht gewählt
Zusatzausstattung 2: Z 71028490: DILO Kalibration, Einstellung |
Code: PMC71-AAA2PBGAAAA |
Code: FMU40-ARB2A2 |
Pressure transmitter
Code: PMC71-1MLC1/125
range: 0-40 bar
(PMC71-UBA1SBTRBTA) |
ELECTRMAGNETIC
Code: 50P2H-AT2B1AA0CBAA |
FTC260-BA2D2 |
Correct: PMC131-A11F1A1T
(CERABAR
TPMC131-A11F1A1T) |
EASYTEMP
TMR31-A1AABBAC1AAA |
MAGNETIC FLOW
10W50-UA0A1AA0A5AA |
MAGNETIC FLOW
10W65-UA0A1AA0A5AA |
MAGNETIC FLOW
10W40-UA0A1AA0A5AA |
MAGNETIC FLOW
10W1H-HC0A1AG2A5AA |
TR12-A2Y1SYC20000,L=140mm
Note: the first “Y” means “special version. Please in-
dicate (see picture of E+H configurator) |
OMNIGRAD M
TR12-A2Y1SXC20000,L=215mm
Note: the “Y” means “special version. Please indic-
ate (see picture of E+H configurator) |
OMNIGRAD T
TR24-AA2AXG3000
Note: Complete product configuration!
Configurator: Option: Immersion Length
ML: ..... mm
Configurator: TMT181 (PCP); 4-20mA,
temp. range to be spec.: TEMP0001/1: °C [Low
range value] must be between -50 °C and 390°C
Configurator: TMT181 (PCP); 4-20mA,
temp. range to be spec.: TEMP0002/1: °C [Up-
per range value] must be between -40 °C and
400 °C
|
TEMPERATURE SENSOR TSV001319-00001 |
TEMPERATURE SENSOR TSV001319-00002 |
TEMPERATURE SENSOR TSV001319-00013 |
Clo and pH sensor
Model: CCA250-B1 |
Correct: RIA45-1035/0
(Model: RIA45-A1C1) |
Liquiphant
FTL260-0020 |
Liquicap
FMI51-A1AGEJW1A1A
Length: 100mm – please check!!
(Code: M FMI51–A1AGEJW1A1) |
Transitter supply
Code: RN221N
Note: Code incomplete, please check |
FMI51-A2AGEJB3A1A
Liquicap M FMI51
Note: Please check the lengths / ranges !!!!
(M-FMI51 A2AGEJB3A1A) |
FMI52-A2AGEJB3A1A
Liquicap M FMI52
Note: Please check the lengths / ranges !!!!
(M-FMI52 A2AGEJB3A1A) |
Level Switch
Code: FTL20H-OTCJ2B
Spec: 10-35VDC,PNP,3-Darht,
Part No:52018579
Serial No:C101EA01092
Connection: Tri-Clamp with diameter 50.5mm |
Level Switch
Code: FTL20H-3TCJ2F
Spec:10-35VDC, PNP, 3-Darht,
Serial No:AA006F01092
Connection: clamp with diameter 50.5mm |
Code: 50P25-EA0A1AA0ABAA |
Flow meter
Code: 50P50-AA0A1AA0ABAA
Promag 50P50, DN50 2" |
FTL50-4TU5/0
Liquiphant M FTL50
(Liquiphant M FTL50
Code: FTL50-UGM2AA2E3A) |
TR11-GBACDSUG2000
RTD Thermometer TR11 |
PMC51-1WU65/0
Cerabar M PMC51
(Cerabar M PMC51
Code: PMC51-CD22QA1PGBRLJA+AA) |
FMU40-ARB2A2
Prosonic M FMU40 |
Model: FTI55-AAB2RV141G1A |
Electromagnetic flow meter
Code: 53P65-EA0B1AA0ABAD |
Type: FTM50-AGG2A4A12AA |
Model: 73F1H-SE4AA1AEA4AW |
Model: 73F50-SE4AA1AEA4AW |
Flowphant
Code: DTT31-A2A111AE2AAB |
Level Transmitter
Code: FMR250-AEE2XCJAA2K |
PMP131-A1101A74 (PMP 131-A1101A74)
Cerabar T PMP131
(CERABAR 0-400BAR) |
Code: PMP131-A4101A1S
Cerabar T PMP131 |
Correct: 73F2F-SA4AA1AAB4AA
Prowirl 73F2F, DN250 10"
(Code: 73F-2FSDIN4AA1AAB4AA) |
Configuration fit TXU10
Code: TXU10-AA |
Level Transmitter
Model: FMI51-A1AGDJB2A2A
L1 = 450mm |
TR10-ABA3CASD52000
60019602
RTD Thermometer TR10 to screw in.
Thermowell acc. DIN 43772/2G+3G.
Replaceable insert, MgO.
max.measuring range: -200...+600oC.
(depending on configuration).
additional specification
Low range value 10,000- °C
Upper range value 50,000 °C
A: Approval: Non-hazardous area
B: Head; Cable Entry: TA30A Alu, IP66/68; M20
A: Pipe Diameter; Material: 9 mm; 316L, DIN43772-2G
3 : Neck Length E: 145 mm, DIN43772-2G
CA: Process Connection: Thread G1/2"; 316L
S: Tip Shape: Straight
D: Immersion Length L: 160 mm
5 :Head Transmitter; Range: TMT180-A12 PCP; 4-20mA,
0.1K; temp. range to be spec. -50/250oC
2 RTD; Wire; Meas. Range; Class; Validity: 1xPt100
TF; 3; -50/400oC; A; -50/250oC increased vibration resistance
0 Material Certificate: Not needed
0 Test Report: Not needed
0 Test/Calibration: Not needed |
73F40-SE4AA1AEA4AA
(code: 73F40-SE4AA1AEA4AA*) |
Correct: LD134-PVA438HB1
(code: CLD134-PVA438HB1) |
TPR100-AXX2CF000
Insert TPR100
Mineral insulated cable (MgO).
Replaceable insert acc.EN60751.
max. measuring range: -200...600oC
(depending on configuration).
A Approval: Non-hazardous area
XX Insertion Length IL: 1.000 mm, as specified
2 Inset Diameter: 6 mm; 316L
C Head Transmitter; Range: Terminal block
F RTD; wire; meas. range; class: validity: 2xPt100
WW; 3; -200/600oC; AA; 0/250°C
0 Factory Test Report: Not needed
0 Calibration: Not needed0
00 Additional Option: Not needed
Please note:
Your seriesnumber is unknown.
(Model: TPR100-AXX2CF2CF000
Seri number: F71071141802PT100/AA/3) |
Deltapilot S FMB70
Code: FMB70-ABA 1H1200 CAA
SPK : PED |
PRESSURE TRADUCER
Code: PMC131-A11F1A1R |
50066789
CLS15-A1M2A
TC 410-1T
(Basic model: Condumax CLS15
Application: pure water, ultrapure water
Materials: 316L, PES
Measuring Range; Cell Constant: 0.04-20uS/cm; k=0.01
Process Connection: thread NPT 3/4", PES max. 120oC (short 140oC)
Cable connection: with 5 m / 15 ft fixed cable
Temperature Sensor: Pt100) |
50066789
CLS15-B1M2A
(Basic model: Condumax CLS15
Application: pure water, ultrapure water
Materials: 316L, PES
Measuring Range; Cell Constant: 0.1-200uS/cm; k=0.1
Process Connection: thread NPT 3/4", PES max. 120oC (short 140oC)
Cable connection: with 5 m / 15 ft fixed cable
Temperature Sensor: Pt100) |
51500495
CLM253-CD0005
(Basic model: Liquisys M CLM253
Field mounting: 247x170x115mm, IP65.
Display: 2-line, 6 languages.
Sensor Input; Software: Conductive sensor; basic version
Power Supply: 230VAC
Output: 1x 0/4...20mA, primary value
Additional Contact: Not selected) |
Capacitive Level Limit Switch
Code: FTI55-AAB2RG143G1A
(FTI55 AAB29RG1 43G1A) |
Electromagnetic flowmeter
10W1H-UC0A1AA0A4AA
50102360 |
FMD77-ABA7F15DAAAA
52017194
Deltabar S FMD77
(Model: FMD77
S/N : ABA7F15DAAAA) |
PMD75-1AA7D11DAAA
52017192
Deltabar S PMD75
(Model: PMD75
S/N : 1AA7D11DAAA) |
PMC51-16AM1/0
71086208
PMC51-AA22QA1PGBTRJB
Cerabar M PMC51
(Successor for your inquired type)
(Code: PMC45-RE11P1-H1LL1) |
Level Switch Soliphant II
Order Code: FTM51-AGJAL4A32AA-L-1000mm |
Levelflex FMP52,
FMP52-AAAABACATLKAA CA=1200 mm |
Code: MB80-12GM50-E0 |
Code: OBT 200-18GM80-E2 |
Liquipoint T
Code: FTW31-A1A2AA0A
Liquipoint T FTW31 ; L=4000mm |
Liquipoint T
Code: FTW31-A1A2AA0A
Liquipoint T FTW31 ; L=4000mm |
PMC133IZ1YOM2562YT2 |
Code: FTL20-0020 |
Transmitter
Type: iTEMP TMT181, head transmitter PCP.
Order Code: TMT181-A31BA
Range: 0-1000C
Out put: 4-20mA
Sensor: PT100 3 wire. |
Bình luận
