Gnexb2X15Ac230Bn1A1R/R - Đèn Báo Khu Vực Khắc Nghiệt - E2S

nergy:

10 Joules (10Ws)

Flash rate:

1Hz (60 fpm), 1.5Hz (90fpm) & double flash

Peak Candela:

1,000,000 cd – calculated from energy (J)

Eff. Intensity cd:

500 cd – calculated from energy (J)

Peak Candela:

110,243 cd – measured ref to I.E.S

Eff. Intensity cd:

479.39 cd – measured ref to I.E.S

Lens colours:

Amber, Blue, Clear, Green, Magenta, Red & Yellow

Voltages DC:

24vdc; 48Vdc

Voltages AC:

115Vac; 230Vac

Ingress protection:

IP66/67

Enclosure matl:

UV stable GRP (glass reinforced polyester)

Colour:

Natural Red – can be provided in alternative colours

Cable entries:

3 x M20 ISO (2 stopping plugs inc.)
Adaptors to M25, 1/2" & 3/4" NPT can be specified

Terminals:

0.5 – 2.5mm² (20-14 AWG)

Enclosure volume:

<2 litres

Line monitoring:

Blocking diode included
EOL Min. 500 Ohm 2w, or 3k3 Ohm 0.5w resistor
or diode (DC versions) can be fitted

Tube life:

Emissions are reduced to 70% after 5 million flashes

Temperature range:

-50° to +70°C (-58°F to +158°F)

Relative humidity:

95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist

Weight:

3.5kg/7.7lbs

*All candela data is representative of performance with clear lens at optimum voltage.

Example part code:

GNExB2X10AC230 [e][m][s][v][x]/[y]
GNExB2X10AC230AB1A1R/R
GNExB2X10 10 Joule Xenon Strobe Beacon, 230V ac,
3 x M20 entries, Brass stopping plugs,
A2 304 SS guard, IECEx & ATEX approved,
Red enclosure

Code: GNExB2X15AC230BN1A1R/R

Code: GNExB2X15AC230BN1A1R/B
